BlackView MP100 AMD R7 5825U/16GB/512GB/1xHDMI+1xDP/RJ45/BT/WiFI/W11P Black |
||
|
Product Appearance |
|
|
|
Type |
Spec. |
Standard Configuration |
|
Product |
Product Type |
MINI PC |
|
|
Dimension |
127*127*45mm |
|
|
Case Material |
Plastic+Metals |
|
System Hardware Configuration |
|
|
|
Type |
Spec. |
Description |
|
CPU |
Model |
AMD Ryzen™ 7 5700U |
|
|
Lithography |
TSMC 7nm FinFET |
|
|
Total Cores |
8 Core ,16 Threads |
|
|
Cache |
L2 cache 4MB,L3 cache 8MB |
|
|
Speed |
1.8GHz |
|
|
Max. Turbo Speed |
4.3 GHz |
|
|
Power Consumption |
25W |
|
GPU |
Model |
AMD Radeon™ Graphics |
|
|
Cores |
8 Core |
|
|
Speed |
1900MHz |
|
|
Max Resolution |
Max Resolution (HDMI) 3840x2160@60Hz,Max Resolution (DP) 3840x2160@144Hz,Max Resolution (Type C) 3840x2160@60Hz |
|
Memory |
Model |
2*SODIMM LPDDR4 (Up to 64GB) |
|
|
Speed |
3200MHz |
|
|
Capacity |
DDR4 Flush-mount,single channel 16GB / Dual channel 32GB |
|
Storage |
SSD |
512GB&1TB(M.2 2280 PCIE3.0 SSD) |
|
|
Interface type |
1* M.2 2280 NVME +1*NVME/SATA3.0,Up to 2TB |
|
|
2.5'' SSD |
Optional, 2.5 inch 7mm SATA port SSD/HDD, Max 2TB |
|
RTC |
BIOS |
Real-time Clock, Time Boot |
|
Auto Power On |
BIOS |
Support auto power on after electrified |
|
Diskless Network |
BIOS |
Support uefi/Legacy Diskless Switch On |
|
TPM |
CPU integratesTPM |
Support TPM 2.0 |
|
multi-screen display |
Video Output |
In the system, HDMI1+DP two-screen display and Type-C three-screen display are supported(Any Type-C port, but does not support dual Type-C simultaneous display) |
|
Heat-dissipating method |
Heat-dissipating method |
Copper tube + copper fin + fan |
|
FAN |
FAN |
5V~0.5A/2.5W /Rated Speed2250rpm |
|
LED |
State |
Button light: blue light running, red light sleeping, atmosphere light: running breathing color RGB (The ambient light is not adjustable and cannot be turned off) |
|
Internet Connection |
|
|
|
Type |
Spec. |
Description |
|
WIFI |
Model |
M.2 E_Key |
|
|
Protocol |
IEEE 802.11 a, b/g, n, ac,ax |
|
Bluetooth |
Model |
M.2 E_Key |
|
|
Protocol |
Support Bluetooth 5.2 |
|
3G |
Built-in |
No |
|
4G |
Built-in |
No |
|
Ethernet |
LAN1 |
10M/100M/1000M Self-adaption |
|
I/O |
|
|
|
Type |
Spec. |
Description |
|
USB |
USB2.0 |
USB2.0 Type-A*1 480Mbps |
|
USB |
USB3.0 |
USB3.2 Gen2 Type-A*2 10Gbps |
|
TF |
Expansion Memory |
No |
|
HDMI |
AV Output |
HDMI 2.0b(Max 4K 60HZ)*1 |
|
DP |
AV Output |
DP1.4(Max 4K 144HZ)*1 |
|
VGA |
Video Output |
No |
|
RJ45 |
Gigabyte Ethernet |
RJ45 1000Mbps *1 Self-adaption |
|
Type C |
Data Transmission |
Type_C *2(full-featured)10Gbps/Max 4K 60HZ |
|
POWER |
Power Button |
x1 |
|
DC IN |
Power Supply Input |
5.5/2.1mm DC Jack x1 |
|
Audio-in/out |
Audio-in/out |
3.5mm Phone Jack x1 (Two-in-one interface) |
|
Antenna1 |
FPC Antenna |
WiFi 2.4+5G+BT x1 |
|
Antenna2 |
FPC Antenna |
WIFI 6.0 |
|
SIM |
Micro SIM |
No Supporting |
|
Software Configuration |
|
|
|
Type |
Spec. |
Description |
|
OS |
Version |
Win11 pro |
|
Environment |
|
|
|
Type |
Spec. |
Description |
|
Environment |
Working Temperature |
0~40? |
|
|
Memory Temperature |
-20~60? |
|
|
Humidity |
90% @ 40 °C (No Condensation) |
BlackView MP100 AMD R7 5825U/16GB/512GB/1xHDMI+1xDP/RJ45/BT/WiFI/W11P Black | ||
Product Appearance |
|
|
Type | Spec. | Standard Configuration |
Product | Product Type | MINI PC |
| Dimension | 127*127*45mm |
| Case Material | Plastic+Metals |
System Hardware Configuration |
|
|
Type | Spec. | Description |
CPU | Model | AMD Ryzen™ 7 5700U |
| Lithography | TSMC 7nm FinFET |
| Total Cores | 8 Core ,16 Threads |
| Cache | L2 cache 4MB,L3 cache 8MB |
| Speed | 1.8GHz |
| Max. Turbo Speed | 4.3 GHz |
| Power Consumption | 25W |
GPU | Model | AMD Radeon™ Graphics |
| Cores | 8 Core |
| Speed | 1900MHz |
| Max Resolution | Max Resolution (HDMI) 3840x2160@60Hz,Max Resolution (DP) 3840x2160@144Hz,Max Resolution (Type C) 3840x2160@60Hz |
Memory | Model | 2*SODIMM LPDDR4 (Up to 64GB) |
| Speed | 3200MHz |
| Capacity | DDR4 Flush-mount,single channel 16GB / Dual channel 32GB |
Storage | SSD | 512GB&1TB(M.2 2280 PCIE3.0 SSD) |
| Interface type | 1* M.2 2280 NVME +1*NVME/SATA3.0,Up to 2TB |
| 2.5'' SSD | Optional, 2.5 inch 7mm SATA port SSD/HDD, Max 2TB |
RTC | BIOS | Real-time Clock, Time Boot |
Auto Power On | BIOS | Support auto power on after electrified |
Diskless Network | BIOS | Support uefi/Legacy Diskless Switch On |
TPM | CPU integratesTPM | Support TPM 2.0 |
multi-screen display | Video Output | In the system, HDMI1+DP two-screen display and Type-C three-screen display are supported(Any Type-C port, but does not support dual Type-C simultaneous display) |
Heat-dissipating method | Heat-dissipating method | Copper tube + copper fin + fan |
FAN | FAN | 5V~0.5A/2.5W /Rated Speed2250rpm |
LED | State | Button light: blue light running, red light sleeping, atmosphere light: running breathing color RGB (The ambient light is not adjustable and cannot be turned off) |
Internet Connection |
|
|
Type | Spec. | Description |
WIFI | Model | M.2 E_Key |
| Protocol | IEEE 802.11 a, b/g, n, ac,ax |
Bluetooth | Model | M.2 E_Key |
| Protocol | Support Bluetooth 5.2 |
3G | Built-in | No |
4G | Built-in | No |
Ethernet | LAN1 | 10M/100M/1000M Self-adaption |
I/O |
|
|
Type | Spec. | Description |
USB | USB2.0 | USB2.0 Type-A*1 480Mbps |
USB | USB3.0 | USB3.2 Gen2 Type-A*2 10Gbps |
TF | Expansion Memory | No |
HDMI | AV Output | HDMI 2.0b(Max 4K 60HZ)*1 |
DP | AV Output | DP1.4(Max 4K 144HZ)*1 |
VGA | Video Output | No |
RJ45 | Gigabyte Ethernet | RJ45 1000Mbps *1 Self-adaption |
Type C | Data Transmission | Type_C *2(full-featured)10Gbps/Max 4K 60HZ |
POWER | Power Button | x1 |
DC IN | Power Supply Input | 5.5/2.1mm DC Jack x1 |
Audio-in/out | Audio-in/out | 3.5mm Phone Jack x1 (Two-in-one interface) |
Antenna1 | FPC Antenna | WiFi 2.4+5G+BT x1 |
Antenna2 | FPC Antenna | WIFI 6.0 |
SIM | Micro SIM | No Supporting |
Software Configuration |
|
|
Type | Spec. | Description |
OS | Version | Win11 pro |
Environment |
|
|
Type | Spec. | Description |
Environment | Working Temperature | 0~40? |
| Memory Temperature | -20~60? |
| Humidity | 90% @ 40 °C (No Condensation) |
