-Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x and IEEE 802.3ab standards
-8 10/100/1000Mbps Auto-Negotiation, Auto-MDI/MDIX ports provide smart switching between 10Mbps, 100Mbps and 1000Mbps hardware
-Non-blocking switching architecture enables full wire-speed packets forwarding and filtering
-Store-and-Forward switching method
-Supports 16K MAC address auto-learning & auto-aging
Standard configurati: 8 10/100/1000M RJ-45 adaptive ports
Switching Capacity: 16Gbps
Throughput: 11.9Mpps
Packet Buffer: 2.5M
MAC Address: 1K
Jumbo Frame: 2K
Transfer Mode: Store and forward
MTBF: 100000 hour
Network protocol
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-TX)
IEEE802.3x (Flow control)
Industry Standard
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD)?EN61000-4-4 (EFT)
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Network Medium
10Base-T : Cat3,4,5 or above UTP(=100m)
100Base-TX : Cat5 or above UTP(=100m)
1000Base-TX : Cat5 or aboveUTP(=100m)
Working Temperature:-10~50°C
Storage Temperature:-40~70°C
Working Humidity :10%~90%,non-condensing
Storage Temperature:5%~90%,non-condensing
Working Height:Maximum10,000 feet
Storage heigh:Maximum 10,000 feet
LED Indicators: PWR(Power indicator) Link(Network Link) LOOP(Loop alarm)
VLAN:Port Isolation, 1-6 ports are isolated each other, all communicate with uplink port 7/8;
Default:Default mode, Support loop alarm;
Extend:Monitor Mode, 1-6 ports support 100M speed reduction negotiation, support 250 meters in 10Mbps/s mode, port 7 and port 8 as uplink port
Product Size:137*77*25mm
Package Size:175*120*63mm
Product Net-Weight:0.3kg
Product Gross-Weight:0.5kg
-Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x and IEEE 802.3ab standards
-8 10/100/1000Mbps Auto-Negotiation, Auto-MDI/MDIX ports provide smart switching between 10Mbps, 100Mbps and 1000Mbps hardware
-Non-blocking switching architecture enables full wire-speed packets forwarding and filtering
-Store-and-Forward switching method
-Supports 16K MAC address auto-learning & auto-aging
Standard configurati: 8 10/100/1000M RJ-45 adaptive ports
Switching Capacity: 16Gbps
Throughput: 11.9Mpps
Packet Buffer: 2.5M
MAC Address: 1K
Jumbo Frame: 2K
Transfer Mode: Store and forward
MTBF: 100000 hour
Network protocol
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-TX)
IEEE802.3x (Flow control)
Industry Standard
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD)?EN61000-4-4 (EFT)
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Network Medium
10Base-T : Cat3,4,5 or above UTP(=100m)
100Base-TX : Cat5 or above UTP(=100m)
1000Base-TX : Cat5 or aboveUTP(=100m)
Working Temperature:-10~50°C
Storage Temperature:-40~70°C
Working Humidity :10%~90%,non-condensing
Storage Temperature:5%~90%,non-condensing
Working Height:Maximum10,000 feet
Storage heigh:Maximum 10,000 feet
LED Indicators: PWR(Power indicator)?Link(Network Link)?LOOP(Loop alarm)
VLAN:Port Isolation, 1-6 ports are isolated each other, all communicate with uplink port 7/8;
Default:Default mode, Support loop alarm;
Extend:Monitor Mode, 1-6 ports support 100M speed reduction negotiation, support 250 meters in 10Mbps/s mode, port 7 and port 8 as uplink port
Product Size:137*77*25mm
Package Size:175*120*63mm
Product Net-Weight:0.3kg
Product Gross-Weight:0.5kg
